Details
EXPAND YOUR HORIZONS
Urrun means “far” in the Basque language. Without a doubt, Urrun is an ebike to take you far and explore distant horizons, but the name holds more significance to us. Urrun is about the long journey we embarked upon with this bike and how far we have come. With new technologies and innovative integrations, it’s safe to say we are proud to have Urrun in the family. Escape, enjoy bigger adventures, go further and explore harder. There are no more excuses.
NEW FRONTIERS
Urrun is ready for life, family and adventure. Our RS Concept with Rise, this is a new riding experience that enhances the joy of biking with smooth assistance that feels as natural and alive as your own body. The lighter weight EP8 RS motor, a 120mm fork and trail ready components mean that Urrun is ready to explore those distant horizons.
NEXT GENERATION ALUMINIUM FRAMES
Next generation aluminium means hydroformed frames, butted tubes and polished welds. It looks great of course, matching the aesthetics of a carbon frame, but more important are the performance benefits and fatigue resistance. We are so confident in our frames that every one comes with a lifetime warranty.
INNOVATE AND INTEGRATE
Urrun brings with it many cutting edge technologies aimed at simplifying the design and removing unnecessary weight. As beautiful to look at as it is to ride, Urrun hardly even looks like an e-bike.
A BETTER BATTERY
Urrun is all about long rides and big adventures. The highly optimised battery offer cutting edge energy density, allowing us to fit more riding into a smaller space, improving aesthetics and reducing weight. Urrun has enough assistance for around 3500m or up to 8 hours of riding.
NATURAL POWER
Urrun uses the same EP8 RS motor as the Rise, developed in partnership with Shimano, to give the most natural-feeling riding experience. Lightweight, quiet, and responsive but above all efficient, Urrun feels as natural and alive as your own body.
Max speed: 20mph
FRAME SIZE | SMALL | MEDIUM | LARGE | X-LARGE |
---|---|---|---|---|
SEAT TUBE (C-T) (mm) | 400 | 453 | 483 | 533 |
TOP TUBE (EFF) (mm) | 565 | 579 | 608 | 645 |
HEAD TUBE (mm) | 110 | 115 | 132 | 153 |
CHAINSTAY (mm) | 445 | 445 | 445 | 445 |
BB HEIGHT (mm) | 322 | 320 | 320 | 320 |
BB DROP (mm) | 54 | 56 | 56 | 56 |
WHEELBASE (mm) | 1143 | 1150 | 1173 | 1220 |
HEAD ANGLE | 65.5º | 66º | 66º | 66º |
SEAT ANGLE | 74.8º | 74.6º | 74.6º | 74.5º |
STANDOVER (mm) | 798 | 826 | 848 | 882 |
REACH (mm) | 395 | 405 | 440 | 460 |
STACK (mm) | 631 | 628 | 647 | 666 |
FORK LENGTH (mm) | 533.5 | 533.5 | 533.5 | 533.5 |
RAKE (mm) | 44 | 44 | 44 | 44 |
FRAME SIZE | RIDER HEIGHT (cm) | RIDER HEIGHT (in) |
---|---|---|
SMALL | 155 - 170 | 5'1" - 5'7" |
MEDIUM | 165 - 180 | 5'5" - 5'9" |
LARGE | 175 - 190 | 5'10" - 6'3" |
X-LARGE | 185 - 200 | 6'3" - 6'7" |
Specs
Motor | Shimano EP600-RS |
---|---|
Pedals | VP-537 Black |
Battery | Orbea Internal 540Wh (Optional 250 Wh Range Extender) |
Charger | Orbea 2.Generation eBike Smart charger 42V/2-4A |
Controller/Display | Shimano EN500 |
Fork | SR Suntour XCR32 LO Coil 120mm Q15x110 Boost |
Stem | Alloy forged, 35mm interface, -6º, ICR |
Chain | Shimano LG500 |
Frame | Orbea Urrun, Shimano Steps, Integrated battery, Hydroformed Alloy 6061 series Internal Cable Routing, Boost 148x12, carrier and kickstand compatible |
Tires | Schwalbe Smart Sam Performance, 29x2.35, Addix, Black |
Brakes | Shimano MT201 Hydraulic Disc |
Saddle | Fortune QF-3091 |
Wheels | Alloy, Tubeless, 29", 29c, 32H |
Headset | FSA 1-1/2" Integrated Aluminium Cup |
Seatpost | Alloy 31.6x300mm Offset 0 |
Shifters | Shimano Cues SL-U4000 |
Handlebars | OC Mountain Control MC31, Rise20, Width 800 |
Rear Derailleur | Shimano Cues U4000 GS Shadow |
Cassette/Freewheel | Shimano CS-LG300 11-46t 9-Speed |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Leo Orange - Black / Small / 29-inch | 8434446495014 | R62716VK | 210000000623 |
Leo Orange - Black / X-Large / 29-inch | 8434446495106 | R62721VK | 210000000625 |
Leo Orange - Black / Large / 29-inch | 8434446495076 | R62719VK | 210000000624 |
